Fra: M-Audio

M-Audio - AIR 192|14

2.099,00

M-Audio - AIR 192|14 - Erobre enhver optagelses-session med professionel studiokvalitet og funktioner!
M-Audio AIR 192 | 14 er en 8-ind 4-ud lydkort med USB / MIDI-interface, der giver alle de forbindelser og software, du har brug for, for nemt at oprette professionelle 24-bit / 192kHz optagelser i studiokvalitet. AIR 192 | 14 har (4) XLR + ¼ ”TRS combo-indgange, (2) ¼” linieindgange og (2) ¼ ”instrumentindgange, der har en specielt designet forstærkning og impedansfase for at give den mest nøjagtige repræsentation af din guitar eller bas, når den er tilsluttet direkte til lydkortet / interface. Der er også MIDI-ind- og udgangsforbindelser, så du kan tilslutte ethvert eksternt midi-gear, du måtte have, såsom eksterne sequencere, trommemaskiner og controllere.

Specifications

Minimum System Requirements

Standard USB 2.0 or USB-C Port

Windows: 7 (32 or 64 bit)

OSX: 10.8

Consult M-Audio.com/support for current software system requirements

Mic Inputs 1-4 (balanced XLR)
FREQUENCY RESPONSE	20 Hz – 20 kHz (+/-0.2 dB)
DYNAMIC RANGE	113 dB (A-weighted)
THD+N	0.003%
PREAMP EIN	-137 dBu (40 Ω source, A-weighted) -129 dBu (150 Ω source, unweighted)
MAX INPUT LEVEL	+14 dBu
GAIN RANGE	62 dB

Line Inputs 1-4 (balanced 1/4" [6.35 mm] TRS)
FREQUENCY RESPONSE	20 Hz – 20 kHz (+/-0.1 dB)
DYNAMIC RANGE	113 dB (A-weighted)
THD+N	0.001% (1 kHz, +4 dBu, -1 dBFS)
MAX INPUT LEVEL	+30 dBu
GAIN RANGE	61 dB

Inst Inputs 5-6 (unbalanced 1/4" [6.35 mm] TS)
FREQUENCY RESPONSE	20 Hz – 20 kHz (+/-0.1 dB)
DYNAMIC RANGE	110 dB (A-weighted)
THD+N	0.001% (1 kHz, +4 dBu, -1 dBFS)
MAX INPUT LEVEL	+16 dBu
INPUT IMPEDANCE	~1 MΩ
GAIN RANGE	59 dB

Fixed Line Inputs 7–8 (balanced 1/4" TRS)
DYNAMIC RANGE	113 dB (A-weighted)
THD+N	0.001% (1 kHz, +4 dBu, -1 dBFS)
FREQUENCY RESPONSE	20 Hz – 20 kHz (+/-0.1 dB)
MAX INPUT LEVEL	+17 dBu

Line Outputs 1–2 (balanced 1/4" TRS)
DYNAMIC RANGE	112 dB (A-weighted)
THD+N	0.002% (1 kHz, -1 dBFS)
FREQUENCY RESPONSE	20 Hz – 20 kHz (+/-0.2 dB)
MAXIMUM OUTPUT LEVEL	+17 dBu

Fixed Line Outputs 3–4 (balanced 1/4" TRS)
DYNAMIC RANGE	113 dB (A-weighted)
THD+N	0.002% (1 kHz, -1 dBFS)
FREQUENCY RESPONSE	20 Hz – 20 kHz (+/-0.2 dB)
MAXIMUM OUTPUT LEVEL	+17 dBu

Headphone Outputs (stereo 1/4")
DYNAMIC RANGE	111 dB (A-weighted, 32 Ω load)
THD+N	0.002% (1 kHz, -1 dBFS, 10 mW/channel into 32 Ω load)
FREQUENCY RESPONSE	20 Hz – 20 kHz (+/-0.2 dB)
MAXIMUM POWER DELIVERED	160mW (<1% THD, 32 Ω load)
MAXIMUM OUTPUT LEVEL	+15 dBu (unloaded)
IMPEDANCE RANGE	32 Ω – 600 Ω

General
OTHER CONNECTORS	(1) 1/8” (3.5 mm) MIDI input (1) 1/8” (3.5 mm) MIDI output (1) USB Type-C port (1) Power adapter input
POWER ADAPTER	12 VAC, 2 A, center-positive (included)
DIMENSIONS (WIDTH X DEPTH X HEIGHT)	10.2" x 7.3" x 3.6" (25.9 x 18.6 x 9.1 cm)
WEIGHT	3.9 lbs. 1.8 kg
