M-Audio - AIR 192|4
M-Audio - AIR 192|4 - Det perfekte valg til soloartister, der ønsker optagelser i studiokvalitet! Med AIR 192 | 4 kan du oprette fejlfri 24-bit / 192kHz optagelser i studiokvalitet med en intuitiv lydgrænseflade der er meget let at bruge. AIR 192 | 4 giver dig mulighed for at optage op til 2 kanaler på én gang med sin dedikerede XLR + ¼” afbalancerede combo-indgang og et helt nyt ¼” instrument-input, der har en specielt designet forstærkning og impedansfase for at give den mest nøjagtige repræsentation af en guitar eller bas, der er sluttet direkte til lydkort / interface.
Key Features
- 24-bit/192kHz resolution for professional recording and monitoring
- Hi-Speed USB circuitry gives you the fastest connection, with a class-leading round trip latency of only 2.59ms*
- Transparent Crystal™ preamps and ultra-pristine A/D converters for unsurpassed audio recording quality
- VU LED meters for dialing in the perfect level
- XLR+¼” TRS combo input with dedicated signal circuit and (1) ¼” instrument input with dedicated signal circuit for the most accurate sound available
- Stereo ¼” outs; ¼” headphone out with independent level control
- Rugged metal chassis; large central control for easy volume adjustment
- USB/Direct knob for balancing between the input signal and the computer signal *Round trip latency is dependent on buffer settings, and computer hardware
What’s In The Box
- AIR 192|4
- USB-C-to-USB-C Cable
- USB-C-to-USB-A Cable
- Software Download Cards
- User Guide
- Safety and Warranty Manual
Specifications
Minimum System Requirements
• macOS: 10.8 Class Compliant
• PC: Windows 7, Windows Driver
• Standard USB 2.0 or USB-C Port
Mic Input 1 (balanced XLR) | |
FREQUENCY RESPONSE | 20 Hz – 20 kHz (+0.1 dB) |
DYNAMIC RANGE | 104 dB (A-weighted) |
SIGNAL-TO-NOISE RATIO | 104 dB (+1.0 dBu, A-weighted) |
THD+N | 0.003% |
PREAMP EIN | -128 dBu (max gain, 150 Ω source, A-weighted) |
MAX INPUT LEVEL | +1.5 dBu |
GAIN RANGE | 55 dB |
Line Input 1 (balanced 1/4" [6.35 mm] TRS) | |
FREQUENCY RESPONSE | 20 Hz – 20 kHz (+0.05 dB) |
SIGNAL-TO-NOISE RATIO | 101 dB (1 kHz, +4 dBu, A-weighted) |
THD+N | 0.003% |
MAX INPUT LEVEL | 16 dBu |
GAIN RANGE | 55 dB |
Inst Input 2 (unbalanced 1/4" [6.35 mm] TS) | |
FREQUENCY RESPONSE | 20 Hz – 20 kHz (+0.05 dB) |
DYNAMIC RANGE | 100 dB (A-weighted) |
SIGNAL-TO-NOISE RATIO | 102 dB (+ 4 dBu, A-weighted) |
THD+N | 0.004% |
MAX INPUT LEVEL | 6 dBu |
INPUT IMPEDANCE | 1 MΩ |
GAIN RANGE | 24 dB |
Main Outputs, L and R (balanced, differential 1/4" [6.35 mm] TRS) | |
FREQUENCY RESPONSE | 20 Hz – 20 kHz (+0.06 dB) |
DYNAMIC RANGE / SIGNAL-TO-NOISE RATIO | 102 dB (A-weighted) |
THD+N | 0.005% |
MAX OUTPUT LEVEL | +7 dBu (1 kHz, -1 dBFS) |
Headphone Output (impedance-balanced 1/4” [6.35 mm] TRS) | |
THD+N | 0.005% |
OUTPUT IMPEDANCE | 10 Ω |
General | |
POWER | USB-bus-powered |
DIMENSIONS (WIDTH X DEPTH X HEIGHT) | 8.0” x 6.0” x 2.76” (20.42 cm x 15.24 cm x 7.0 cm) |
WEIGHT | 2.0 lbs. 0.9 kg |
