Hammond B-3P mk2. ** på bestilling **

133.340,00

Hammond B-3P mk2 - Super lækkert transportabelt hammondorgel ("P" for portabel), ligesom B-3 mk2 er det en nøjagtig dublikation / kopi af Hammond´s originale B-3, men med moderne letvægts digital teknologi. For første gang tilbydes Hammond B-3 i et "let-at-flytte" kabinet, der er simpelt at sætte op og transportere.



Samme specifikationer som Hammond B-3 MK2, men med transportabelt kabinet (Se evt. Hammond B-3 MK2)

  • Stunning Retro Styling in a portable cabinet
  • Exact same specification as the B-3 mk2
  • MIDI OUT
  • Awesome Stage Presence
  • This is the ULTIMATE Hammond Organ
  • Check it out and you will be very impressed
  • Digital Tone Wheel™ Sound Engine
  • Direct Analogue Keying™



Digital Tone Wheel™ Sound Engine and Direct Analogue Keying™

The unique Hammond B-3 sound is reproduced by a revolutionary newly designed sound generator system (96 digital Tone Wheels). This new digital Tone Wheel generator perfectly generates pure tones that is tones which have no harmonic content of their own. This purity is essential in order to attain a desirable tonal cohesion between the fundamental and its harmonics when they are mixed through the use of the drawbars.

When a manual key is pressed, it closes 10 small electrical switch contacts. These contacts are connected to the digital Tone Wheel generator as well as to the drawbars. The positions of the drawbars (which are under control of the player) determine the intensities of the individual electrical currents corresponding to the fundamental and its harmonics. After leaving the drawbars, the various electrical currents are connected together (or "mixed") to form a single complex current which flows from the console to the Leslie cabinet where it is amplified to operate the speakers. The swell pedal varies the intensity (or volume) of this complex current before it reaches the speakers.



The Registration Principle of the Hammond Organ

This is the original, unique feature of the Hammond Organ which makes it completely different from any other organ. In the Hammond Organ, the basic elements of all musical tones (the fundamental and its harmonic overtones) are made separately available to the organist. Furthermore, their relative strengths may be adjusted at the will by the organist. The drawbars of the Hammond Organ are provided for this purpose. Flute-like tones, for instance, may be produced by a certain combination of these drawbars; string-like effects by another combination; or the effects of both strings and flutes by still a different combination of the same drawbars. Thus, the drawbars provide the tonal ingredients from which the various registrations may be compounded.



Pre-Set Combinations

Each manual of the organ is equipped with nine pre-set combination keys. In addition, there are two sets of manually adjustable controls for each keyboard, thus making twenty-two different registrations which are instantly available, in addition, of course, to the many thousands of variations available by adjustment of the "harmonic drawbars". "VIBRATO AND CHORUS" has six possible positions corresponding to three degrees of vibrato and three degrees of vibrato chorus. The control pre-selects the extent of vibrato or vibrato chorus which will be obtained when either of the manual vibrato "ON/OFF" stops is used.

Touch Response Percussion Control

Percussion tones may be produced with a key-controlled "touch-response" in which desired notes of a melody may be accentuated. Now at your touch are effects like harp, chimes, orchestral bells, celeste, xylophone, marimba and a whole new world of fascinating percussion tones, which may be expressively introduced in a manner not found on any other organ.

Information Center

The drawbars, control tablets and rotary controls affect the operations necessary for performance on the organ. Advanced features such as drawbar voice mode, pedal sustain length etc., are accessed using the Information Center. This allows the player to see and make changes. The Information Center Display and touch buttons are located on the left side of the instrument just below the stylish music-rest.

The Selective Vibrato Stops

The great and swell manuals are provided with separate "ON/OFF" vibrato controls in the form of tilting stop tablets. The rotating control "VIBRATO AND CHORUS" has six possible positions corresponding to three degrees of vibrato and three degrees of vibrato chorus. The control pre-selects the extent of vibrato or vibrato chorus which will be obtained when either of the manual vibrato "ON/OFF" stops is used.

Leslie Speaker Connection

The B-3P mk2 Hammond Organ is equiped with a 11-pin Leslie connector, making it easy to connect a genuine Leslie Speaker to the organ.

Model/varenr.: B-3P mk2
Vægt: 79 kg

Levering, Fragt, Returret

Andre købte også
The B's in comparison...
  B-3P mk2 B-3 mk2 Old B-3
Keyboards 61-61-25 61-61-25 61-61-25
Preset Key 12keys
Mechanical Latch
12keys
Mechanical Latch
12keys
Mechanical Latch
Drawbars
Swell (Upper) 9 pitches 2 sets 9 pitches 2 sets 9 pitches 2 sets
Great (Lower) 9 pitches 2 sets 9 pitches 2 sets 9 pitches 2 sets
Pedal 2 pitches 2 pitches 2 pitches
Preset Memory Compact Flash-card Compact Flash-card Change by Preset Panel
Keying Method Direct Analog Keying™ Direct Analog Keying Direct Analog Keying
Contact 10-Mechanical contacts
+Rubber contacts for velocity
10-Mechanical contacts
+Rubber contacts for velocity
9-Mechanical contacts
Polyphony Full Polyphony Full Polyphony Full Polyphony
Generator (Manual) 96-Digital Tone Wheels™ 96-Digital Tone Wheels™ 91-Tone Wheels
Gen. Waveform Changeable by CFcard
(Flash ROM)
Changeable by CFcard
(Flash ROM)
Fixed
Generator (Pedal) VASE II VASE II Tone Wheels
Vibrato/Chorus V1, V2, V3, C1, C2, C3
SWELL ON, GREAT ON
V1, V2, V3, C1, C2, C3
SWELL ON, GREAT ON
V1, V2, V3, C1, C2, C3
SWELL ON, GREAT ON
Leslie SLOW, STOP, FAST SLOW, STOP, FAST SLOW, FAST
Control OVERDRIVE
REVERB
OVERDRIVE
REVERB

Tone Control BASS, TREBLE BASS, TREBLE
Terminal LINE IN, LINE OUT
11p-LESLIE SOCKET
HEADPHONE
MIDI-OUT
LINE IN, LINE OUT
11p-LESLIE SOCKET
HEADPHONE
MIDI-OUT
PHONO INPUT
6p-LESLIE SOCKET
Ext Memory Slot COMPACT FLASH CARD COMPACT FLASH CARD
Display 20x2 digits LCD 20x2 digits LCD
Weight 79 kg 132 kg 190 kg
Dimensions Without pedal in cm :
133W x 73D x 97H
Closed, without pedal in cm :
123W x 73D x 97H
Open, with pedal/bench in cm :
123W x 126D x 117H
Closed, without pedal in cm :
123W x 73D x 97H
Open, with pedal/bench in cm :
123W x 126D x 117
